Home Tools

SM-164

Catalog No. T12932L CAS 957135-43-2

SM-164 binds to XIAP protein containing both the BIR2 and BIR3 domains (IC50: 1.39 nM). It acts as an extremely potent antagonist of XIAP.

All products from TargetMol are for Research Use Only. Not for Human or Veterinary or Therapeutic Use.

SM-164, CAS 957135-43-2

Pack Size	Availability	Price/USD
1 mg	In stock	$ 119.00
2 mg	In stock	$ 173.00
5 mg	In stock	$ 289.00
10 mg	In stock	$ 443.00
25 mg	In stock	$ 718.00
50 mg	In stock	$ 996.00

Bulk Inquiry

Select Batch

Purity: 99.92%

Purity: 97.25%

Biological Description

Chemical Properties

Storage & Solubility Information

Description	SM-164 binds to XIAP protein containing both the BIR2 and BIR3 domains (IC50: 1.39 nM). It acts as an extremely potent antagonist of XIAP.
Targets&IC50	CIAP2:1.1 nM (Ki), CIAP1:0.31 nM (Ki)
In vitro	SM-164 binds to XIAP being 300 and 7000-times more potent than its monovalent counterparts and the natural Smac AVPI peptide, respectively. The binding affinities of SM-164 to XIAP, cIAP-1, and cIAP-2 proteins are determined using fluorescence-polarization based assays. SM-164 concurrently interacts with both BIR domains in XIAP and functions as an ultra-potent antagonist of XIAP in both cell-free functional and cell-based assays. SM-164 targets cellular XIAP and effectively induces apoptosis at concentrations as low as 1 nM in leukemia cancer cells while having minimal toxicity to normal human primary cells at 10,000 nM. SM-164 has a Ki value of 0.56 nM to XIAP protein containing both BIR2 and BIR3 domains. SM-164 has a Ki value of 0.31 nM to a cIAP-1 protein containing both BIR2 and BIR3 domains. SM-164 binds to cIAP-2 BIR3 protein with Ki values of 1.1 nM [1][2].
In vivo	SM-164 is highly effective in the inhibition of tumor growth and capable of achieving tumor regression in the MDA-MB-231 xenograft model. SM-164 (1 mg/kg) treatment fully inhibits tumor growth during the treatment. SM-164 (5 mg/kg) treatment reduces the tumor volume from 147±54 mm3 at the beginning of the treatment (day 25) to 54±32 mm3 at the end of the treatment (day 36), a reduction of 65%. The strong antitumor activity by SM-164 is long-lasting and not transient. SM-164 (5 mg/kg) is statistically more effective than Taxotere at the end of the treatment (P<0.01) or when the tumor size in the control group reached 750 mm3 (P<0.02) [2].

Molecular Weight	1121.42
Formula	C62H84N14O6
CAS No.	957135-43-2

Storage

Powder: -20°C for 3 years | In solvent: -80°C for 1 year

Solubility Information

DMSO: 5.2 mg/mL (4.64 mM), Sonification is recommended.

References and Literature

1. Sun H, et al. Design, synthesis, and characterization of a potent, nonpeptide, cell-permeable, bivalent Smac mimetic that concurrently targets both the BIR2 and BIR3 domains in XIAP. J Am Chem Soc. 2007 Dec 12;129(49):15279-94. 2. Lu J, et al. SM-164: a novel, bivalent Smac mimetic that induces apoptosis and tumor regression by concurrent removal of the blockade of cIAP-1/2 and XIAP. Cancer Res. 2008 Nov 15;68(22):9384-93.

Citations

1. Huang F, Liang J, Lin Y, et al.Repurposing of Ibrutinib and Quizartinib as potent inhibitors of necroptosis.Communications Biology.2023, 6(1): 972. 2. Li J, Liu X, Liu Y, et al.Saracatinib inhibits necroptosis and ameliorates psoriatic inflammation by targeting MLKL.Cell Death & Disease.2024, 15(2): 122. 3. Chen D, Chen Y, Feng J, et al.Guanine nucleotide exchange factor RABGEF1 facilitates TNF-induced necroptosis by targeting cIAP1.Biochemical and Biophysical Research Communications.2024: 149669.
